Key Features
- Intelligent Low Stroke (iLS) pump cell
- Low unfolding height
- Same pedestal than the 36Z
- LED Lights
- Complete Water Tank Solution
Technical Details
General Information
| Number of sections | 4 |
| Vertical Reach | 105’4″ |
| Horizontal Reach | 100’1″ |
| Unfolding Height | 24’11” |
| Rotation | 365 deg |
| End Hose Length max. | 10′ |
| End hose – Diameter | 5 “ |
| Outrigger spread L-R – front hydraulically extended out & down | 18’1″ |
| Outrigger spread L-R – rear hydraulically swing out & extend down | 23’1″ |
| Length x Width x Height | 35’7″ x 8’2″ x12’10” |
| Front Axle Weight | 18641 lbs |
| Rear Axle Weight | 32833 lbs |
| Total Weight (approx.) | 51474 lbs |
| Wheelbase | 223 “ |
Concrete Pump Cell .17 iLS
| Material Cylinder Diameter-Stroke Length | 10/83 “ |
| Output (piston side) | 222 yd³/hr |
| Delivery Pressure (piston side) | 1233 psi |
| Strokes (piston side) | 28 |
Concrete Pump Cell .16 H
| Material Cylinder Diameter-Stroke Length | 9 |
| Output (rod side) | 209 yd³/hr |
| Output (piston side) | 141 yd³/hr |
| Delivery Pressure (rod side) | 1233 psi |
| Strokes (rod side) | 31 |
