Key Features
- Putzmeister hydraulic circuit and the latest core pump technology for maximum efficiency and up to 45 % oil saving
- Intuitive operation thanks to Ergonic® 3.0
- All information on the display of the remote control. Complete control and all the information at the workplace at all times
- Continuous delivery line with nominal diameter of DN 125/5″
- Small support width with flexible support, space-saving structure
- Robust and steady thanks to reinforced substructure, compact boom pedestal and TRDI support
- Lower service costs with maintenance-free components and smaller quantities of operating fluids, consumables, etc.
- Lower weight with TRDI support structure compared to the 63Z-Meter with TRDV support
Technical Details
General Information
| Number of sections | 6 |
| Boom Style | RZR_>Folding |
| Vertical Reach | 194’3″ |
| Horizontal Reach | 177’10” |
| Reach from Front of Truck | 167′” |
| Reach Depth | 144’8″ |
| Unfolding Height | 42’8″ |
| Rotation | 365 deg |
| End Hose Length max. | 10′ “ |
| End hose – Diameter | 5 “ |
| Delivery Line | 5″/1302 psi |
| Outrigger spread L–R – front hydraulically extended out & down | 39’11” |
| Outrigger spread L–R – rear hydraulically swing out & extend down | 36’1″ |
| Length × Width × Height | 48’2″ × 8’2″ × 13’2″ |
| Front Axle Weight | 53,780 lbs |
| Rear Axle Weight | 53,540 lbs |
| Total Weight (approx.) | 107,320 lbs |
| Wheelbase | 334 “ |
Concrete Pump Cell .19 iLS
| Material Cylinder Diameter–Stroke Length | 10/83 “ |
| Output (piston side) | 254 yd³/hr |
| Delivery Pressure (piston side) | 1233 psi |
| Strokes (piston side) | 31 |
Concrete Pump Cell .17 iLS
| Material Cylinder Diameter–Stroke Length | 10/83 “ |
| Output (piston side) | 222 yd³/hr |
| Delivery Pressure (piston side) | 1233 psi |
| Strokes (piston side) | 28 |
