Autonomous, convenient and cost-effective pile backfilling with the new crawler concrete pump with Stage V engine

BSC 1409 D5 Performance Line combines the best performance of our BSA 1409 concrete pump with powerful crawlers and 150 kW Stage V diesel engine, allowing it to work autonomously tracking bore pile drilling machine, and ensuring maximum efficiency for your project.

This model belongs to Performance Line, a serie characterized by the Putzmeister’s quality and performance and in which the equipment is firmly defined, limiting the customer specific adaptations, what means wide availability at attractive prices.

Add to Cart
BSC 1409 D5 performance line
BSC 1409 D5 performance line
R0,00
Contact us on WhatsApp

Free nationwide shipping on all orders over R5000.00

  • 15 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

BSC 1409 D5 performance line
BSC 1409 D5 performance line
R0,00
Contact Us
Please enable JavaScript in your browser to complete this form.

Key Features

  • Putzmeister concrete pump
  • Steel crawler chassis with optional rubber pads
  • Remote control for output and translation
  • On-built complete cleaning system
  • On-site maintenance
  • Options required for daily work

Technical Details



General Information

Output 97 m³/hr
Delivery Pressure 71 bar
Strokes 110
Engine Deutz, 150 kW
Engine Emissions V
Material Cylinder Diameter-Stroke Length 200/140 mm
Outlet Diameter 125 mm
Length x Width x Height 6062x200x250 mm
Weight 795 kg
Chassis Steel Crawler
Max. Speed 1,7 km/hr
Diesel Tank 120 l
Water Pump 50 l/min, 20 bar
Compressor 820 l/min
Pressured Air Tank 60 l
