M 760 Stage V Green Efficiency

R0,00

Eco-Friendly Screed Pump with 59.7 hp (44.5 kW) Diesel Engine

The environment friendly and powerful M 760 Stage V Green Efficiency screed pump has been developed for big tasks. The Deutz diesel engine (Emissions Level Stage V) with a new compressor unit and an energy saving watercooler, offers even more power: specifically 59.7 hp (44.5 kW). That means more power for lower fuel consumption, emissions and noise.

It can be used to pump cement screed, calcium sulfate screed (anhydrite), magnesia screed and sand and aggregate.



The Mixokret M 760 Stage V Green Efficiency is available in 3 versions:

1. M 760 DH Diesel (Basic version)

2. M 760 DHB (Diesel and feeder)

3. M 760 DHBS (Diesel, feeder and scraper)

Add to Cart
M 760 Stage V Green Efficiency
M 760 Stage V Green Efficiency
R0,00
Contact us on WhatsApp

Free nationwide shipping on all orders over R5000.00

  • 15 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

M 760 Stage V Green Efficiency
M 760 Stage V Green Efficiency
R0,00
Contact Us
Please enable JavaScript in your browser to complete this form.

Key Features

  • Maximum power – meets all requirements of the current “Stage V” emission category
  • Higher output and more efficient through machine performance management in series
  • Hydraulic mixing unit with overload protection and reverse
  • New robust keypad improves usability
  • Auto-Power-Off – prevents the battery from draining overnight
  • Large diesel tank with 70 litres volume
  • User-friendly operation of feeder lever and air taps
  • Optimised maintenance and service features
  • Robust design ensures value retention and high resale values
  • Made in Germany



Technical Details



General Information



Mixing Vessel 200 l
Horizontal Reach 190 m
Vertical Reach 135 m
Delivery Pressure 8 bar
Compressor 4.8 m³/min
Engine Diesel, 3-cylinder Deutz with turbocharging
Engine Power 44.5 kW
Engine Emissions Stage V
Diesel Tank 70 l
Max. Aggregate Size 16 mm
Chassis braked

M 760 DHB Stage V

Output 4.8 m³/hr
Weight 184 kg
Length × Width × Height 5075 × 148 × 2431 mm
Filling Height 400 mm

M 760 DH Stage V

Output 4 m³/hr
Weight 1715 kg
Length × Width × Height 478 × 148 × 152 mm
Filling Height 820 mm

M 760 DHBS Stage V

Output 5 m³/hr
Weight 190 kg
Length × Width × Height 5075 × 148 × 2431 mm
Filling Height 400 mm
