Key Features
- No counter weight necessary
- Easy operation of the climbing device
- Placing boom operated by remote control
- Working platform for safe operation
- Quick separating column, easy to assemble
Technical Details
General Information
| Boom Style | Z |
| Horizontal Reach | 34.7 m |
| Reach Depth | 28. m |
| Rotation | 540 degree |
| End Hose Length max. | 3 m |
| Delivery Line | DN 125 |
| Boom Weight | 560 kg |
| Pedestal Weight | 250 kg |
Configuration
RS 850 Tubular Column 29′ 6″ (9.00 m)
| Length | 9 m |
| Width | 1 m |
| Weight | 449 kg |
RS 850 Tubular Column 19′ 7″ (6.00 m)
| Length | 6 m |
| Width | 1 m |
| Weight | 2786 kg |
RS 850 Tubular Column 9′ 8″ (3.00 m)
| Length | 3 m |
| Width | 1 m |
| Weight | 1631 kg |
RS 850 Climbing Column 34′ 5″ (10.50 m)
| Length | 10.5 m |
| Width | 1 m |
| Weight | 4767 kg |
RS 850 Climbing Column 5′ 0″ (1.50 m)
| Length | 1291 m |
| Width | 1 m |
| Weight | 1291 kg |
