Key Features
- Large mixer/hopper for more efficient working
- Water metering pipe in the mixer grill prevents blockages
- Lifting mixer with low filling height for convenient filling
- Conforms with CE standards, simple and clear operation
- Fully hydraulic pump and mixer drive with an infinitely variable delivery rate up to 60 l/min
- Quiet 3-cylinder 21.8 hp (16.3 kW) Kubota engine (Stage V)
- Optimal soundproofing thanks to double-walled canopy
- Optimal manoeuvrability thanks to low drawbar load
- Lasting value thanks to high resale value
Technical Details
General Information
| Feed Hopper | 7.8 ft³ |
| Mixing Vessel | 6.4 ft³ |
| Pump | 2L6 |
| Output | .12–2.1 ft³/min |
| Horizontal Reach | 398′ 8″ |
| Vertical Reach | 196′ 10″ |
| Compressor | 2-cylinder, 14.1 ft³/min |
| Delivery Pressure | 102 psi |
| Engine | Diesel, 3-cylinder Kubota |
| Engine Power | 21.8 hp |
| Engine Revolutions | 260 rpm |
| Engine Emissions | 5 |
| Weight | 165 lbs |
| Length × Width × Height | 139 |
| Filling Height | 31.5″ |
| Max. Aggregate Size | .23″ |
| Chassis | Without brakes, approved for road use |
