SP 25 DQR

R0,00

Outstanding performance for a wide variety of applications

The powerful worm pump SP 25 DQR with compulsory mixer is suitable for a variety of other special applications such as concrete renovation or filling and grouting work, in addition to classic interior and exterior plastering. The increased efficiency focuses on higher throughputs, as well as longer conveying distances and higher delivery pressures.

Multicomponent materials and ready-mix dry mortar can be mixed on the construction site in the powerful compulsory mixer for any mixing time. The lifting function of the mixer allows a lower filling height and permits the simple transfer of the mixed batch to the conveyor hopper.

Add to Cart
SP 25 DQR
SP 25 DQR
R0,00
Contact us on WhatsApp

Free nationwide shipping on all orders over R5000.00

  • 15 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

SP 25 DQR
SP 25 DQR
R0,00
Contact Us
Please enable JavaScript in your browser to complete this form.

Key Features

  • Robust design – tested in construction site use and on the test track
  • Large lifting mixer with 63.4 gal (240 l) volume allows mixing of larger material quantities/containers
  • Lower filling height facilitates filling and cleaning of mixer
  • Central control with intuitive keypad and clearly arranged display
  • Larger tank for maximum operational performance without refuelling
  • Support legs for optimal stability on the construction site
  • Robust plastic cover according to the highest quality standard
  • Safe transfer of machine with crane – thanks to integrated crane lugs

Technical Details

General Information

Mixing Vessel 8.47 ft³
Feed Hopper 8.8 ft³
Output .18–2.6 ft³/min
Delivery Pressure 508 psi
Horizontal Reach 230′
Compressor 2-cylinder 400 l/min, 7 bar
Pump Worm pump 2L6
Engine 3-cylinder Kubota Diesel (Stage V)
Engine Power 37.5 hp
Weight 2315 lbs
Length × Width × Height 14′ × 4′ 6″ × 4′ 9″
Filling Height 2′ 5″
Max. Aggregate Size .23″ (2L6), .31″ (2L75)
Chassis braked, approved for road use
